| Terminal Design | Cell Layout | ||
|---|---|---|---|
| Type | ØD |  |
|
| Positive | Negative | ||
| T2 | 19.5°-0.3 | 17.9° -0.3 | |
 |
|||
| Dimensions (mm) | |||
|---|---|---|---|
| Length | Width | Height | T.Height |
| 500 | 178 | 210 | 255 |
 |
|||
| Electrical Specification | |
|---|---|
| Rated Capacity (20 Hour Rate @ 6.00 A) | 120 Ah |
| Reserve Capacity | 180 Min. |
| Cold Cranking Performance @ 0oF (-18oC) | 575 A |
| Discharged Characteristics @ 25oC (70oF) |
|---|
 |
| Discharged Characteristics @ -18oC (0oF) |
|---|
 |
